Product Details
Type
Electronic Lab Trainer
Country of Origin
India
Model Name/Number
CES 301
Power
230V AC +/- 10 %
Frequency Range
1 hz to 1 mhz in six decade steps
Output Voltage
(1) Sine Wave 0 - 10V in 4 decade steps of 10V,1V,0.1V & 0.01V with continuously variable cont
Port
Courier
Payment Terms
L/C, D/A, D/P, T/T
Delivery Time
2-3 day
WIDE RANGE SINE/SQUARE OSCILLATOR 1Hz TO 1MHz
MODEL - CES 301
Power - 230V AC +/- 10 %
Frequency range - 1 hz to 1 mhz in six decade steps
Dial accuracy - +/-3% of full scale
Wave form - Sine and square wave
Sine wave distortion - Less than 0.5% from 100 hz to 100khz
Square wave rise time Less than 100 neno sec. at maximum output
Square wave symmetry - Duty factor variable from 0% to 80%
Output impedance - 600 ohm +/- 5%
We are pleased to present Square Audio Oscillator from our premium range of Oscillators backed by the technological expertise of professionals and our vast domain experience.
Looking for "Sine/Square Oscillator 1hz To 1mhz" ?
