0.1Hz To 1MHz Laboratory Function Generator

FUNCTION GENERATOR 0.1Hz To 1MHz
Wave Form : SINE, SQUARE & TRIANGLE WAVE, Amplitude : 0 - 20V p/p
MODEL - CES 306
Type -   Analog

Frequency  -       0.1 hz to 1 mhz in six decade range

Power Supply    -  230v ac +/- 10%

Output Amplitude  -       0 - 20v p/p for all function

Deal accuracy - +/- 5% of range

WAVE FORMS   - Sine , Square & Triangle , Ttl Square Wave (separate O / P)

SINE WAVE DISTORTION -            Less than 1% from 100 Hz to 100KHz

SQUARE WAVE DUTY CYCLE        - 49% To 51%

SQUARE WAVE RISE TIME -          Less than 100 nano Sec. At maximum amplitude

OUTPUT IMPEDANCE  -                 600 Ohm + 5%

“CROWN” Function Generator 0.1Hz To 1MHz is capable of providing the site , SQUARE, TRIANGLE Wave form. It has linear frequency scale very low Distortion & constant signal amplitude with the output signal symmetry about Zero. The DC coupled output provides square wave without any appreciable Sag at low frequency. It has a maximum 20V P/P amplitude. The output is protected against short circuit. It has an offset control provided to shift the base line of the signal by + 10V. The continuously variable DC offset control further enhance the versatility of the instrument. The equipment is used in Audio Electronics & other Laboratory & Research work.
