programmable timer

MODEL -

1) UTR - 9611

Size - 96x96x50 mm

2) UTR - 7211

Size -72x72x85 mm

3) UTR - 4811

Size - 48x48x95 mm

Display -

Upper : 7 segment, 4 digit, 0.56" RED LED – Time

Lower : 7 segment, 4 digit, 0.4" GREEN LED - Set Time

INPUT

Start Pulse - Micro switch / Limit switch / Proximity

Start Pulse Type - Power ON / Enable / Trigger

OUTPUT -

Control Output - 2 - Relay (2 C/O, 5A, 230V AC), SSR (12V DC approximately) (Optional)

SPECIFICATION -

Set Point - 1 - Set Point - (Delayed ON/ Instant ON) (Configurable)

2 - Set Point - (Cycle Mode)

Operating Mode - Delayed ON / Instant ON / Cycle Mode (Configurable)

Reset Facility - Front & Back Both Reset Available

Time Setting Range - 99.99 / 999.9 / 999 sec, 99.59 min/sec, 999.9 min, 9999 min, 999.9 hrs, 9999 for hrs, 99.59 hrs/min (Configurable)

Counting Direction - Up / Down (Configurable)

Memory retention - Yes / No (Configurable)

Parameter lock - ON / OFF (Configurable)

Power Supply - 230V AC, 10%, 50hz 90-270V AC/DC, 50/60 Hz, SMPS

Indication - LED for Relay Status Indication

Enclosure Material - Plastic

Operating Ambient Temp - o o 0 C to 55 C

Relative Humidity - Upto 95% RH Non Condensing
